Heavy Duty Turning Lathe

Your Professional Heavy Duty Turning Lathe Supplier

Anyang Xinsheng Machine Tool Co.,Ltd.since 1946. with 50 50-year history of designing and manufacturing of machine tools, is the largest machine tool manufacturer in central China. Conventional Lathe,CNC Lathe,CNC Slant Lathe, Sphere Turning Lathe,CNC Vertical Lathe.

Why Choose Us

Certificates

Top 10 overall efficiency of enterprise" and "one hundred key enterprises in Henan Province"; take the lead in implementing national industry standards ISO09001, ISO14001, GB/T28001, AAAA-level standard of good conduct, and other international and domestic corporate management system certifications and evaluations.

Foreign trade market

Our machines have been exported to more than 100 countries and regions, and provide long-term overseas technical guidance and after-sales service for these countries.

Advanced Equipment

Advanced production lines, with five-sided machining center, large floor milling machine, Large German rail grinder, Zeiss CMM, gear detector and laser interferometer, and other advanced equip- meant, a pparatus, more than 600 pieces(sets).

Professional team

We are in possession of a group of highly competent technical personnel, a market oriented experienced sales team. In the gesture of sincere cooperation, we strive to establish a promise keeping and quality .

Heavy Duty Turning Lathe Specifications

Swing over bed	Mm	500
Swing over cross slide	Mm	250
Distance between centers	Mm	1000/1500/2000
Spindle bore	Mm	82 (Optional 130)
Spindle bore taper	-	Metric φ90/1:20
Spindle nose type	-	A2-8(A2-11)
Spindle speed steps	-	Stepless
Spindle speed range	Rpm	1800 (Optional 800)
Turret/tool post	-	Electric 4 position
Tool size	Mm	25 x 25
X axis travel	Mm	300
Z axis travel	Mm	1000/1500/2000
X axis rapid traverse	Mm/min	6000
Z axis rapid traverse	Mm/min	10000
Tailstock quill diameter	Mm	75
Tailstock quill taper	-	MT5
Tailstock quill travel	Mm	200
Main spindle motor	Kw	7.5
Coolant pump motor	Kw	0.125
Total rated power	Kw	11
Total rated current	A	23
Weight for 1000	Kg	2900
Weight for 1500	Kg	3300
Weight for 2000	Kg	3700
Dimension for 1000	Mm	2950x1700x1800
Dimension for 1500	Mm	3650x1700x1800
Dimension for 2000	Mm	4250x1700x1800

Key Features

This serles lathe machine is sultable for intemal and external turning, tapering, and other rotating faces, metric.module and inch threads, as well as drilling and pull oil slot.

Width of bed is bigger than normal lathe machine, with high hardness on guideway,. the guideway is through high-frequency quenching,wear-resisting.

This machine is easy to operate, with rapld device for carriage, design with single hand wheel to operate.

The strenath and rigidity of machine is higher than normal lathe machine, high eficiency, suitable for heavy duty machining.

Types of Heavy Duty Turning Lathes Available

Heavy-duty engine lathe machine

With variations in sizes, a common detail about these machines is that they work on metals with large diameter ranges.

Extra heavy-duty lathe machine

Extra heavy-duty lathe machines are commonly used in industries like oil and gas, power generation, marine industries, and aerospace and defense.

Tool room heavy-duty lathe machine

Although similar to engine heavy-duty lathe machines, a key difference between tool room heavy-duty lathe machines and engine heavy-duty machines is that the former are made to produce tools.

Modified heavy-duty lathe machine

Normally, heavy-duty lathe machines have straightforward operating and control systems to handle workpieces that need polishing or cutting.

Applications

01/

Machine shops and manufacturing industry
In machine shops and the manufacturing industry, heavy-duty bench lathes are frequently utilized

02/

Automotive industry and repair shops
Heavy-duty lathes play a vital role in the automotive industry and repair shops.

03/

Aerospace and aviation industry
The aerospace and aviation industries rely on precision engineering to guarantee the performance and safety of aircraft parts.

04/

Medical and healthcare industry
The heavy-duty lathe is a crucial machine tool in the medical and healthcare industry. These workpieces may include precision components and implants requiring high biocompatibility.

Shipping

We can ship by United States Postal Service (USPS) or by United Parcel Service (UPS); the choice is yours. You can also use your own Customer Account with UPS or FEDEX and will be asked to provide valid account information. Finally, you can pick up locally at our warehouse in Pasadena, CA.

Our Certificates

productcate-1-1

FAQ

Q: How can I choose the most suitable machines?

A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .You can also send us the products drawing ,we will choose the most suitable machines for you.

Q: What's your main products of your company?

A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on.

Q: What is your trade terms?

A: FOB, CFR and CIF all acceptable.

Q: What's the Payment Terms?

A: T/T ,30% initial payment when order ,70% balance payment before shipment ;

Q: What's the MOQ?

A: 1 Set .(Only some low cost machines will be more than 1 set )

Q: What is your after-sales service?

A: The warranty of our machine is 12 months. During this period of non-human causes of failure, we will communicate with customers online, if you need to replace the parts, we will free mail.

As one of the most professional heavy duty turning lathe manufacturers and suppliers in China, we're featured by quality products and good price. Please rest assured to wholesale high-grade heavy duty turning lathe in stock here from our factory.
