15kg/33lbs Blacksmithing Power Hammer

Our blacksmith air hammer is a top-notch tool designed specifically for the forging industry. It has a unique long hammer bar design, providing greater flexibility and comfort for your operation. Whether you're creating forged knives, wrought iron, kitchen knives, hatchets, or decorative wrought iron, our products can help.

Send Inquiry

Description

33lbs/15KG blacksmithing POWER HAMMER PARAMETERS

Ram weight: 15kg / 33lbs.
Blows per min: 300.
Die face(mm): 70*50.
Tup axis to frame -D (mm): 170.
Working height(mm): 920.
Height includes base H2 (mm): 1570.
Floor space L1*L2(mm): 920*600.
Total weight(Kg): 540.
Motor: single phase/ 2.2KW/1440RPM.

Introduction of the blacksmithing power hammer

Anyang STH-15 balcksmithing power hammer is self-contained power hammer is a type of forging hammer that integrates all necessary components within a single, compact unit. This design makes it highly convenient and efficient for blacksmiths and metalworkers. Here are the key characteristics and benefits of a self-contained power hammer.

advantages

anyang power hammer

Integrated Components:
Motor: The power source (usually an electric motor) is built into the hammer, eliminating the need for external power sources like compressors or hydraulic systems.
Mechanism: All mechanical parts, such as the crankshaft, connecting rod, and hammer head, are contained within the unit..

Compact Design
Space-Saving: The all-in-one design takes up less space in the workshop compared to traditional power hammers that require separate power units.
Portability: Some models are designed to be relatively portable, allowing for easier relocation within the workshop or even transport to different sites..

Motor solid frame casting.
Anyang STH series power hammer adope high-quality one-piece iron casting, good surface, heavy anvil part. Make the power hammer strong enough, and reduce the forging vibration.
