Products Description
QKP1219 Threaded CNC Lathe is mainly developed for the turning of oil pipe threads. It is suitable for all kinds of pipe thread turning, and can also be used as a general lathe, such as turning internal and external cylindrical surfaces, taper surfaces, end surfaces and grooves. This lathe has the functions of automatic tool compensation, rough turning workpiece circle, thread cutting circle, grooving circle, etc. It can also set the absolute zero position arbitrarily. It can be used for turning cylindrical and conical threads and their continuous connection threads, as well as face threads. Our CNC pipe thread lathe is medium-sized machining equipment with excellent performance, featuring high efficiency, high finishing qualification rate, convenient programming and easy operation. Welcome to contact us for more product information and price.
Machine parameters
| ITEM | UNIT | QKP1219/1223 |
| External Dia. of pipes | mm | 190/230 |
| Swing over bed | mm | 800 |
| Swing over carriage | mm | 480 |
| Max.length of workpiece | mm | 1000/1500/2000/3000 |
| Max.length of turning | mm | 800/1300/1800/2800 |
| Span of guideway | mm | 600 |
| Spindle nose | A2-15 | |
| Taper hole of spindle | Metric 213/1:20 | |
| Spindle bore | mm | 200/240 |
| Top taper of spindle | 6# | |
| Range of spindle speed | r/min | 20~600 |
| Chuck | mm | 500 |
| Min. feed of X/Z-axis | mm | 0.001/0.001 |
| Max. travel of X | mm | 420 |
| Turret type | V4 300 | |
| Section of tool shank | mm | 40x40 |
| Indexing repeatability | mm | 0.008 |
| Max.cutting force | N | 19600 |
| Dia. of tailstock | mm | 100 |
| Travel of tailstovk | mm | 250 |
| Taper hole of tailstock | Morse6 | |
| Main power | kw | 15 |
| Accuracy | IT6-IT7 | |
| Roughness | RA1.6 | |
| Length | mm | 3605/4105/4645/5600 |
| Width | mm | 2219/2330 |
| Hight | mm | 1830/2100 |
| CNC system | FANUC 0i-TF/Siemens 808 (can be customized according to user requirements) |
Product Details
Features
1. Safe operation of the product: the sliding box has a safety structure that prevents damage to the lathe due to overloading.
2. Scientific design: the bed adopts rectangular guideway with good stability. The spindle adopts three-support structure, which has the advantages of high rigidity, high precision, and strong cutting force to meet customers' demands.
3. Support customisation: users can choose special configuration or special order according to the size and usage of the workpiece.
