Products Description
The AD series CNC lathe is a high-speed precision CNC machining equipment produced by introducing Japanese technology.It is suitable for machining various kinds of the shaft,sleeve,and dish-type parts with complicated shapes,such as turning cylindrical-conical surface,circular surface,end surface, groove cutting,chamfering,hole reaming,etc.
Standard accessories:(AD25/35)
1.Domestic motor:X/Z motor is GSK motor.
2.Hydraulic tailstock,hydraulic turret,hydraulic chuck.
3.X/Z imported precision ball screw.
4.Spindle bearings and ball screw bearings are Japan NSK.
5.Imported electrical components,hydraulic components.(AD25 domestic)
6.Fully enclosed chip guard,air conditioning for electric cabinet.
Optional(AD25/35)
1.Other system;
2.Special hydraulic tailstock,hydraulic rotating tailstock:
3.Special required chuck and turret;
4.Hydraulic steady rest.
5.Chip removal machine.
If you need more detailed product information, please click the button below to contact us.
Product Parameter
Main structural features
1.The machine bed is cast with a box-shaped structure,adopts one-piece casting technology,completely machined by the pentahedral machining center at a one-time clamping process,the accuracy is maintained well.
2.Adopt high rigidity 45 inclined machine bed.The sliding surface of the cross slide adopts plastic veneer technology to make the feed system rigid,frictional resistance,and other dynamic and static characteristics In the best condition.A separate sink is attached to prevent leakage and easy to maintain.
3.The hydraulic turret is adopted,and the tool holder can be interchanged at any position.It can rotate nearby to change the tool at will.The tool change speed is fast and the action is stable and reliable.
4.High rigidity spindle structure,there is no gear structure in the spindle box,greatly reducing noise and vibration.
5.Equipped with hydraulic chuck and high-speed cylinder,and equipped with foot switch,workpiece clamping is convenient,safe,and reliable.
6.The X and Z-axis feed drives use large-diameter,high-precision ball screws,and are preloaded and pre-drawn,ensure movement and position accuracy.
7.The lathe has full-chip protection,electric control cabinet safety device,safe operation door,and reinforced glass design of the operation door to ensure the safety of machinery and personal.
Our Products
Exhibition
FAQ
Q: What is your minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.
Q: What CNC system do you use?
A: FANUC, SIEMENS, MISTSUBISHI, GSK etc. It depends on your choice.
Q: When is the delivery time?
A: We will delivery it within 90 days after received your payments.
Q: How to handle the warranty period?
A: During the warranty period, because of product quality problems, the company is responsible for free maintenance, if need to change parts, we be responsible for free replacement.
If the machine problem is not belonging to our machine quality problems, when the buyer needs us send engineers to give repairing service, we charge the appropriate cost.
Q: Can your company send the technical personnel to our company and direct our workers for free?
A: When the machine arrive the buyer's installation site, we timely send mechanical and electrical engineers to install according to the buyer's schedule. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
