CKB6180/100 horizontal lathe machine heavy duty cnc lathe
The CKB6180/61100 Series are economical and practical CNC lathes designed for reliable performance and high efficiency. Featuring optimized structural design, consistent quality, user-friendly programming, and easy operation, these machines are ideal for machining complex shafts, sleeves, and disk-shaped workpieces.
They are capable of performing a wide range of turning operations, including internal and external cylindrical surfaces, conical surfaces, arcs, various threads, as well as drilling, boring, and reaming. These lathes are particularly well-suited for processing small to medium batches of diversified parts, offering high versatility, productivity, and precision with minimal defect rates.
Due to their excellent adaptability and performance, the CKB6180/61100 Series are widely used across industries such as automotive manufacturing, petroleum equipment, military production, and more.
Product parameters
| Swing over bed | 800/1000mm |
| Max.turning dia | 480/680MM |
| Max.length of workpiece | 1000/1500/2000/3000/4000/5000/6000mm |
| Pan of guideway | 600mm |
| Spindle bore | 100/140mm(optional) |
| Range of spindle speeds | 8-800r/min |
| Main motor power | 15kw |
| Max weight of workpiece | 2000kg |
Product Configuration
Standard Configuration
1. Manual tailstock;
2. Manual ⌀400 three-jaw self-centering chuck;
3. 240×240 vertical four-station electric tool turret;
4. Guarding for models below 6000;
5. Automatic lubrication and cutting fluid system.
Optional Configurations
1. Hydraulic, rotary tailstock;
2. Hydraulic chuck;
3. Vertical 6-station, horizontal 6/8-station electric tool turret;
4. Tool follower, center support, automatic chip conveyor, etc.;
5. Deep-hole boring device.
Product Features
Heavy-duty Design
The bed, spindle, and other key components are made from high-strength cast iron castings or welded steel structures, providing exceptional rigidity and load-bearing capacity for machining large workpieces. The lathe's guideways adopt wide rectangular or triangular composite designs, finished with high-precision grinding to reduce vibration and deformation during cutting, ensuring stable and accurate performance.
Multi-Functional Integration
In addition to traditional lathe functions, it also offers composite machining capabilities such as drilling, boring, milling, and tapping. This lathe can complete most of the machining for complex parts in a single setup, reducing workpiece clamping frequency and turnaround time. The machine is equipped with multi-station tool holders that can accommodate various tools and support automatic tool changing, adapting to diverse machining requirements
CNC and High Precision
The multi-functional CNC lathe adopts a high-performance CNC system, supporting multi-axis interpolation, enabling precise programming and machining of complex surfaces. The spindle system uses high-precision bearings and variable frequency speed control technology, offering a wide speed range with high positioning accuracy and repeatability. It is equipped with closed-loop feedback devices such as linear scales and encoders, which monitor motion positions in real-time and correct errors to ensure stable machining accuracy.
Automation and Adaptability
The product can be integrated with automatic feeding mechanisms, robotic loading/unloading systems, and online measurement devices to achieve unmanned or semi-automated production, thereby improving processing efficiency. For the clamping requirements of heavy-duty workpieces, it is equipped with large-sized chucks, centers, center frames, and tool followers to ensure reliable positioning of the workpiece during processing.
Our Certificates
why choose us?
Our company has advanced production lines equipped with state-of-the-art machinery, including five-axis machining centers, large floor-type milling machines, large German rail grinders, Zeiss CMMs, gear inspectors, and laser interferometers. We have assembled a highly professional and skilled team of experts in mechanical engineering, electrical engineering, hydraulics, casting, testing, standardization, information technology, intelligence, and safety, dedicated to the research and innovation of CNC machine tools. We are committed to providing you with high-quality products. Please feel free to contact us!
